Butterfly valves regulate and control the flow of fluids through pipelines, making them a vital component in manufacturing. They are highly versatile, operating by means of a circular disc or plate that rotates around an axis, facilitating or blocking the flow of fluids through the valve. These valves are available in several types, each with specific features and unique advantages.
Selecting the right kind of butterfly valve for your application is critical to guaranteeing the most efficient performance and dependability.
Types of Butterfly Valves
Wafer butterfly valves are the most frequently used in their class and are an affordable option across many applications. They are compact and lightweight with a thin profile and are easy to install between flanges. They are optimal for use in water treatment, food processing, and HVAC industries, where automated on/off control is needed.
Lug butterfly valves are similar to their wafer counterparts, but they feature threaded inserts or lugs on their body. This design facilitates installation between flanges, as nuts and bolts are only necessary on one side. This makes them appropriate when one side of the pipeline is difficult to access—although the lugs increase the overall weight and size of the valve. Lug butter fly valves can be used in the petrochemical, pharmaceutical, and mining industries.
Double-offset butterfly valves permit a tighter seal and better control than other butterfly valve varieties. They are appropriate for high-pressure and high-temperature applications and are most often utilized in the oil and gas industry, as they are less vulnerable to leakage and have an extended service life.
Triple-offset butterfly valves are similar to double-offset valves but have an additional offset in their disc and shaft, which means that a gasket between the valve seat and disc is not required. The design guarantees a bubble-tight seal and minimizes the incidence of leakage. Triple-offset valves are utilized when zero leakage is needed, such as in the chemical and petrochemical industries. They offer an extended service life, demand less maintenance, and hold up to wear and tear more effectively than other types of butterfly valves.
Which Valve is Right for Your Operations?
Selecting the correct valve for your application requires thoughtful consideration of several factors, such as the associated fluid, temperature, pressure, and flow rate. Wafer butterfly valves are best for low-temperature and low-pressure applications, while double-offset and triple-offset butterfly valves are appropriate for high-pressure and high-temperature applications.
The best option will also take into account the end connections, construction materials, and the need for automation. Speaking with an experienced valve reseller can help you choose the appropriate butterfly valve for your specific situation.
To Recap: Choosing the Right Valve
Butterfly valves are a vital pipeline component necessary for regulating and controlling the flow of fluids. Selecting the correct kind of butterfly valve can significantly affect the safety, performance, and reliability of your manufacturing application. Wafer butterfly valves are affordable and versatile, while lug butterfly valves are best for applications where one side of the pipeline is difficult to access. Double-offset and triple-offset butterfly valves deliver a tighter seal and are appropriate for critical applications. By considering the unique needs of your operations and application and consulting with a knowledgeable valve supplier, you can be assured of the best performance and longevity of your butterfly valve.
